118 Series 6-Chamber Aluminium Casement Window
The flagship · largest casement lights in the range.
118 SIX CHAMBER THERMAL-BREAK CASEMENT WINDOW 2.0 · application scenes
The flagship casement
The 118 series is the flagship of the Adam Alux window range: a six-chamber thermal-break casement window at 118 mm depth with 2.0 mm wall thickness. It is specified for the largest casement lights in the product line and for facades that take full weather exposure.
It carries the full feature set of the thermal-break family, tuned for the largest module in the range.
Built-in features
Eight features, standard on the line.
- 016063-T5 A-grade primary aluminium · high strength, high crack resistance
- 02Multi-chamber profile body: layered sound insulation, thermal blocking, higher pressure resistance
- 035 mm insulating glass with integrated bent spacer bars
- 04Thermal-break design forming an effective cold/hot bridge barrier, cutting overall energy use
- 05High-transparency, rust- and corrosion-resistant insect screen · better daylight, stronger insect protection
- 06EPDM foam gaskets, aging-resistant, raising the sealing and water-tightness grades
- 07Drainage design for fast water discharge and easy cleaning
- 08Low-profile glazing bead resists dust build-up, widens the sightline and lifts the wind-load index
Gallery
More views of the series
Specification
The numbers, as published.
Values below are the published specification of the 118 Series 6-Chamber Casement Window. The complete dimensional and hardware-layout pack (section drawings, gasket schedule, hardware set) is supplied with the quotation.
- Opening
- Hinged sash, multi-point lock
- Profile depth
- 118 mm
- Chamber structure
- 6 chambers, polyamide thermal-break bridge
- Wall thickness
- 2.0 mm
- Insulating glass
- 5 mm - 27 A - 5 mm · single / double / triple
- Sealing
- EPDM foam gaskets, open drainage
- Insect screen
- High-transparency mesh, standard
- Standard finishes
- Sand grey · Coffee · Metallic grey (ext. & int.) · RAL and two-tone on request
- Dimensional pack
- Supplied with quotation
Colours
Standard finishes
- Sand greyext / int
- Coffeeext / int
- Metallic greyint
Visual reference only · production colours to RAL or matched swatch, two-tone exterior/interior supported on the thermal-transfer line.
Profile & engineering
Six chambers and a 2.0 mm wall give the 118 the highest section stiffness in the casement range. Standard insulating glass is 5 mm-27 A-5 mm, and the wider glazing bead keeps the sight-line narrow even across large lights. The series includes the family feature set: integrated bent spacers, EPDM foam sealing, high-transparency insect screen, open drainage and multi-point locking. Where a project needs a casement that opens wider than the 110 or 112 lines comfortably do, the 118 is the line to specify.
Where it performs
High-end residential towers, penthouse and lake-view buildings, exposed coastal and high-altitude facades, and projects where the single-light size is the constraint. OEM partners building a premium window line also start from this series.
Finishes & customisation
The widest standard colour set in the range: sand grey, coffee and metallic grey across exterior and interior faces, with two-tone combinations and RAL matching on the thermal-transfer line.
OEM & project supply
The full OEM programme applies as standard: private-label packing, project documentation, export-standard containers. Profile samples and a finished test window are available before commit, and the quotation ships with the complete dimensional and hardware-layout pack.
Market versions
The same series, quoted for your market
Each market page adds the local section on top of the published specification: the codes and certification position, the glazing the schedule calls for, and the container plan.
FAQ
Asked on every 118 series project
What is the largest single light the 118 series can carry?
Large-light limits are quoted against your floor height, glazing weight and wind-load zone; the dimensional pack for your configuration ships with the quotation.
What insulating glass is standard on the 118 series?
5 mm-27 A-5 mm insulating glass as standard, with single, double and triple glazing configurations available.
Do you support OEM / private label on this series?
Yes · RAL-matched finishes, private-label packaging and project documentation are part of our standard OEM programme.
