50 Series Casement Window for Australia
The 50 Series Casement Window is configured here for Australia. The figures below are the published catalogue specification of the series; the market section covers what projects in Australia add to it. Send the opening schedule and the glazing you want, and the quotation comes back with the dimensional pack.
50 Series Casement Window · Australia
50 Series Casement Window
The entry line. A dependable casement at production price points. The complete configuration, glass options and finish list are on the window series page.
- Opening
- Casement (hinged), multi-point lock
- Profile depth
- 50 mm
- Chamber structure
- Multi-chamber profile body
- Wall thickness
- 1.2 mm (6063-T5)
- Insulating glass
- 5 mm - 20 A - 5 mm standard · single / triple on request
- Sealing
- EPDM foam gaskets, open drainage
- Insect screen
- High-transparency mesh, standard
- Standard finishes
- Anodised · thermal transfer, RAL on request
- Dimensional pack
- Supplied with quotation
Engineering
Multi-point lock layout that fabricators already know
Narrow sight-line: the glass, not the frame, carries the elevation
Extruded on the same main line as the 110 and 118 series
EPDM gaskets with an open, self-cleaning drainage path
5 mm-20 A-5 mm insulating glass standard, single and triple on the same bead
OEM terms: private-label packing, sample profile set and a finished test window
What Australian spec writers check
The Australian regime is built on testing, not on brand claims. AS/NZS 1170.2 sets the regional wind-load classification, AS 2047 defines how window and door assemblies are tested against wind load, and AS 1288 classifies the glazing itself. A cyclone-rated specification must therefore state the zone class, the tested configuration and the glazing classification for the exact module size.
Adam Alux does not hold AS 2047 test certificates. Engineering against your zone and module schedule is confirmed at quotation, and a finished test window or door can be produced before the production run.
Shipping to Australia
Modules travel to the major Australian ports in export-standard containers, packed upright with edge protection. The container count for your schedule depends on frame depth and glass build-up, so the loading plan comes with the quotation.
Transit and port handling are confirmed per shipment. For coastal projects, the fluorocarbon and anodised finish lines are the standard shortlist against salt-air exposure.
Projects in Australia
villa · day scene
Coastal house, full-height glazing
A raised concrete deck and full-height glazing turn the elevation toward the water, under a deep shaded veranda.
apartment · day scene
Apartments, angled sunshades
Pale render with dark metal balcony bands and angled sunshades over floor-to-ceiling framed windows.
villa · day scene
Terrace house, glass rear extension
The original brick frontage stays intact, with a slim-profile aluminium and glass extension reading as a separate volume.
FAQ
Frequently asked
Do your aluminium windows and doors ship to Australia?
Yes. Modules ship to the major Australian ports in export-standard containers, with the loading plan for your schedule included in the quotation.
How do you handle cyclone zone specifications?
The zone class and the module schedule drive the specification. Engineering and glazing classification are confirmed at quotation against the AS 2047 and AS 1288 requirements, with a test unit available before production.
Can we get samples of the 50 series before committing to a project?
Yes. Sample profiles and a finished test window are available on request, matched to your glazing and hardware choices. Sample lead time is confirmed with your enquiry.
Can the 50 series be upgraded to thermal break?
Yes. When a project needs thermal-break performance, the 110, 112 and 118 series are the step-up lines in the range; we will help re-specify your modules against the new profile.
Keep going
Series, market and range
Send your opening schedule
Series, glazing and finish come back as one quotation for Australia, with the full dimensional pack on PDF and CAD on request.
