Market · the United States
50 Series Casement Window for the United States
The 50 Series Casement Window is configured here for the United States. The figures below are the published catalogue specification of the series; the market section covers what projects in the United States add to it. Send the opening schedule and the glazing you want, and the quotation comes back with the dimensional pack.
50 Series Casement Window · the USA
50 Series Casement Window
The entry line. A dependable casement at production price points. The complete configuration, glass options and finish list are on the window series page.
- Opening
- Casement (hinged), multi-point lock
- Profile depth
- 50 mm
- Chamber structure
- Multi-chamber profile body
- Wall thickness
- 1.2 mm (6063-T5)
- Insulating glass
- 5 mm - 20 A - 5 mm standard · single / triple on request
- Sealing
- EPDM foam gaskets, open drainage
- Insect screen
- High-transparency mesh, standard
- Standard finishes
- Anodised · thermal transfer, RAL on request
- Dimensional pack
- Supplied with quotation
Engineering
Multi-point lock layout that fabricators already know
Narrow sight-line: the glass, not the frame, carries the elevation
Extruded on the same main line as the 110 and 118 series
EPDM gaskets with an open, self-cleaning drainage path
5 mm-20 A-5 mm insulating glass standard, single and triple on the same bead
OEM terms: private-label packing, sample profile set and a finished test window
What US projects require
Glazing rules tighten in the high-velocity hurricane zones: the code requires impact-rated glazing and defined structural performance on the exterior envelope, and most spec writers work from the ASTM and Florida building code framework as the reference point. In practice the glazing build-up, the frame section and the hardware have to be stated on the quotation, line by line, against your zone and wind-borne debris category.
Adam Alux does not hold US test certifications. The bridge is the specification process: send the zone, the debris category and the opening schedule, and the glazing build-up, frame section and hardware layout come back confirmed against that project at quotation, with a finished test unit available before production.
Shipping to US ports
Modules ship in export-standard containers sized around the opening: glazed units travel upright with corner and edge protection for the trans-Pacific line. The loading plan, including modules per container for your mix, comes with the quotation, because it depends on frame depth and glass build-up rather than a fixed table.
Freight and port handling are confirmed per shipment, and transit time is quoted at order. Packing list and conformity documentation travel with the container.
Projects in the United States
villa · day scene
Two-storey house, charcoal and timber
A charcoal clad upper volume sits over a timber lower floor, with slim black frames and a cantilevered balcony.
villa · day scene
Suburban house, brick and pivot door
White brick and timber under a low-pitched roof, with black casement windows and a pivot entrance leaf.
apartment · day scene
Mid-rise apartments, brick podium
A brick podium carries a lighter upper volume, with a regular grid of framed windows and juliet balconies.
FAQ
Frequently asked
Do your aluminium windows and doors ship to the USA?
Yes. The range ships to US ports in export-standard containers, and the loading plan for your opening mix is included with the quotation.
How is hurricane-zone glazing handled on a quotation?
The glazing build-up for a designated zone is confirmed line by line against your debris category at quotation. A finished test unit is available before production.
Can we get samples of the 50 series before committing to a project?
Yes. Sample profiles and a finished test window are available on request, matched to your glazing and hardware choices. Sample lead time is confirmed with your enquiry.
Can the 50 series be upgraded to thermal break?
Yes. When a project needs thermal-break performance, the 110, 112 and 118 series are the step-up lines in the range; we will help re-specify your modules against the new profile.
Keep going
Series, market and range
Send your opening schedule
Series, glazing and finish come back as one quotation for the United States, with the full dimensional pack on PDF and CAD on request.
